XLR 3 Pin Female Heavy Duty TOP Connector NC3FX1-TOP
Neutrik
Part No
CONE8MXBTOP
NC3FX1-TOP
3 pole female cable connector, TRUE OUTDOOR PROTECTION (TOP), gold contacts
The X-TOP series is a "heavy-duty" XLR cable connector for outdoor use. Outdoor protected by mating with related cable/chassis connector of the XLR TOP range (IP65).
Gold contacts are standard.
Features & Benefits
- Heavy-duty sealed XLR connector range for harsh and demanding environment
- Outdoor protection according to IP65
- Uses high impact UV-resistant materials
- TOP - True Outdoor Protection in consideration of UL50E
Technical Information
- Connection Type: XLR
- Gender: Female
Electrical
- Capacitance between contacts: ≤ 4 pF
- Contact resistance: ≤ 3 mΩ
- Dielectric strength: 1,5 kVdc
- Insulation resistance: > 10 GΩ (initial)
- Rated current per contact: 16 A
- Rated voltage: < 50 V
Mechanical
- Cable O.D.: 5.0 - 8.0 mm
- Insertion force: ≤ 20 N
- Withdrawal force: ≤ 20 N
- Lifetime: > 5000 mating cycles
- Wiresize (mm²): Max. 1.5 mm²
- Wiresize (AWG): Max. 16 AWG
- Wiring: Solder contacts
- Locking device: Latch lock
Material
- Bushing: UV-resistant rubber
- Contact plating: Gold (Au) over Nickel (Ni)
- Contacts: Bronze (CuSn8)
- Insert: Polyamide (PA66)
- Locking element: St3K32 (latch) / Ck 67 (spring)
- Shell: Zinc diecast (ZnAI4Cu1)
- Shell plating: Nickel
- Strain relief: Polyacetal
- Sealing jacket: UV-resistant rubber
Environmental
- Flammability acc. to UL94: V0 (insert)
- Standard compliance: IEC 61076-2-103
- Protection class acc. to OEC 60529: IP 65 (mated)
- Solderability standard: IEC 60068-2-20
- Temperature range: -30 °C to +80 °C
- Polltion degree acc. to IEC 60664-1: II
| Weight | 1.41oz |
|---|
